192FB AIR-COOLED DIESEL ENGINE SERIES
Model	HR192FB
Type	Single-cylinder,vertical,4-stroke air-cooled diesel engine
Combustion System	Direct Injection
Bore×Stroke (mm)	92×75
Displacement capacity (cc)	498
Speed (rpm)	3000	3600
Max.output (kw)	8.5	9
Rated output (kw)	8	8.5
Fuel	o# or-10# light diesel oil
Fuel oil tank volume (l)	5.5
Lubricatiom oil volume (l)	1.65
Fuel oil consumption rate (g/kw.h)	275
Starting system	Recoil or Electric
PTO rotation direction	It is clockwise as viewing from the flywheel end
Dimension (mm)	510x470x560
Gross weight (kg)	47
20FT QTY	176
