10hp single cylinder engine part diesel engine pump

Model	HR186F		HR186FA		HR188FA
Type	Single-cylinder,vertical,4-stroke air-cooled diesel engine
Combustion System	Direct Injection
Bore×Stroke(mm)	86×70		86×72		88×72
Displacement capacity(cc)	406		411		438
Speed(rpm)	3000	3600	3000	3600	3000	3600
Horse power(hp)	9		10		12
Max. output(kw)	6	6.5	6.3	6.8	7.5	8
Rated output(kw)	5.5	6	5.8	6.3	7	7.5
Fuel	o# or-10# light diesel oil
Fuel oil tank volume(L)	5.5		5.5		5.5
Lubricatiom oil volume(L)	1.65		1.65		1.65
Fuel consumption rate(g/kw.h)	≤278		≤280		≤280
Starting system	Recoil or Electric
PTO rotation direction	It is clockwise as viewing from the flywheel end
Dimension(mm)	417×470×494				417×470×494
Net weight(kg)	48		59		59
