1.8KW single phase diesel generator with quick connector

Product Categroies

1.8KW single phase diesel welding generator
Brief introduction：
1.8KW single phase diesel welding generator,diesel engine,electrical engine,diesel generator,Made in china,
E-mail: smart@kubaoya.com
Follow us:
Inquiry Now

Model	DG6000EW
Frequency (HZ)	50	60
Rated Output (KW)	1.8	2.2
Rated Speed (rpm)	3000	3600
Rated AC Voltage (V)	220, 230, 240
Power Factor	1
Weling No-load Voltage (V)	55-65
Working Voltage (V)	26-30
Rated Current (A)	180
Welding Efficiency	60%
Phase	Single phase
Noise Level (at 7m)	80-85
Fuel Tank Capacity (L)	12.5
Continues Running Time (hr)	6
Engine Model	HR186FA
Engine Type	single-cylinder, vertical,4-stroke air-cooled diesel engine
Bore×Stroke (mm)	86×72
Displacement Capacity (cc)	418cc
Fuel Consumption Rate (g/kw.h)	≤280
Fuel	0# or -10# light diesel oil
Lubrication Oil Volume (L)	1.65L
Combustion System	Direct Injection
Voltmeter	Yes
AC Output Socket	2
AC Circuit Breaker	Yes
Oil Warning Light	Yes
Oil Alert	Yes
22AH Battery	Yes
DC Circuit Breaker	Yes
Hour Meter	Optional
Current Meter	Optional
Remote Control	Optional
ATS	Optional
30AH Battery	Optional
36AH Battery	Optional
Wheel and Handle	Optional
L×W×H (mm)	760×520×620
Net Weight (kgs)	102
20FT Load Quantity	102
